Model:6320-6338,6403-6418
Model:6320-6338,6403-6418 – 浏览次数：1 –时间：2010-12-06
Product details：

Deep Groove Ball Bearing are particularly versatile.They are simple in design, non-separable,suitable for high and even very high speeds and are robust in operation,requiring little maintenance.Deep raceway grooves and the close conformity between the raceway grooves and the ball enable deep groove ball bearings to accommodate axial loads in both directions, in addition to radial loads,even at high speeds.Single row deep groove ball bearings are the most widely used bearing type.



Designations Old spec Principal Dimensions (mm) Basic load rating (KN) Speed ratings(rpm) Weight(kg)
d D B Dynamic Staitc Grease Oil
6320 320 100 215 47 163 134 2800 3600 7.09
6321 321 105 225 49 173 146 2600 3400 8.05
6322 322 110 240 50 160 166 2400 3200 9.53
6324 324 120 260 55 212 190 2200 3000 12.2
6326 326 130 280 58 228 216 1900 2600 14.77
6328 328 140 300 62 255 245 1800 2400 18.33
6330 330 150 320 65 280 290 1700 2200 21.87
6332 332 160 340 68 310 325 1600 2000 26.43
6334 334 170 360 72 350 380 1500 1900 31.14
6336 336 180 380 75 340 400 1400 1800 35.7
6338 338 190 400 78 360 425 1400 1800 49
　 　 　 　 　 　 　 　 　 　
6403 403 17 62 17 17.45 11.9 12000 15000 0.27
6404 404 20 72 19 23.81 16.78 10000 13000 0.4
6405 405 25 80 21 29.42 21.33 9000 11000 0.53
6406 406 30 90 23 36.41 26.78 8500 10000 0.74
6407 407 35 100 25 43.76 32.55 7000 8500 0.95
6408 408 40 110 27 50.39 37.97 6700 8000 1.25
6409 409 45 120 29 59.52 45.55 6000 7000 1.55
6410 410 50 130 31 70.99 55.55 5300 6300 1.9
6411 411 55 140 33 77.44 62.71 5000 6000 2.3
6412 412 60 150 35 83.94 70.3 4800 5600 2.75
6413 413 65 160 37 90.88 78.33 4500 5300 3.3
6414 414 70 180 42 107.31 99.53 3800 4500 4.85
6415 415 75 190 45 118.25 114.78 3600 4300 6.8
6416 416 80 200 48 125.55 124.88 3400 4000 8
6417 417 85 210 52 157 138 3200 3800 9.5
6418 418 90 225 54 193 158 3000 3600 11.5
